9HT series multifunctional feed grinding and mixing unit integrates a hammer mill crusher with a vertical/horizontal multi-screw mixer, delivering fast grinding and high mixing uniformity for small and medium pig farms and breeding enterprises to formulate their own rations.
| Parameter | 9HT-500 (Vertical) | 9HT-1000 (Vertical) | NPW-HFM-2000 (Horizontal) | NPW-HFM-3000 (Horizontal) |
|---|---|---|---|---|
| Model Code | NPW-FGM-05 | NPW-FGM-10 | NPW-FGM-20H | NPW-FGM-30H |
| Mixing Batch Capacity | 500 kg / Batch | 1,000 kg / Batch | 2,000 kg / Batch | 3,000 kg / Batch |
| Grinding Throughput | 500 ~ 1,000 kg / h | 1,000 ~ 1,500 kg / h | 1,500 ~ 2,500 kg / h | 2,500 ~ 3,500 kg / h |
| Crusher Motor Power | 3.0 kW | 7.5 kW ~ 11.0 kW | 15.0 kW Heavy Hammer Mill | 15.0 kW Heavy Hammer Mill |
| Mixer Motor Power | 3.0 kW | 3.0 kW | 4.0 kW Dual-Ribbon Auger | 5.5 kW Dual-Ribbon Auger |
| Mixing Homogeneity | CV ≤ 8% (High Uniformity) | CV ≤ 8% | CV ≤ 5% (Precision Ribbon Blend) | CV ≤ 5% |
| Grinding Screen Size | Φ 1.5 mm ~ Φ 4.0 mm Mesh | Φ 1.5 mm ~ Φ 4.0 mm Mesh | Quick-Change Segmented Screens | Quick-Change Segmented Screens |
| Dust Collection System | Integrated Pulse Dust Filter Bags | Pulse Dust Collection Bags | Heavy Cyclone Filter Separator | Cyclone Dust Collector |
| Machine Dimensions (L×W×H) | 2300 × 1000 × 2400 mm | 2500 × 1250 × 2800 mm | 2500 × 1550 × 3100 mm | 2500 × 1650 × 3200 mm |
