NPW stainless steel nursery and fattening single/double-sided automatic feed trough series, made of premium 304/201 stainless steel with laser cutting and CNC bending with folded edges, anti-arching with no dead corners and no residue, effectively saving more than 1% of feed.
| Parameter | Nursery Double-Sided | Nursery Single-Sided | Fattening Double-Sided | Fattening Single-Sided |
|---|---|---|---|---|
| Model Code | NPW-SST-ND | NPW-SST-NS | NPW-SST-FD | NPW-SST-FS |
| Hole Configurations | 6, 8, 10, 12 Holes Available | 3, 4, 5, 6 Holes Available | 6, 8, 10, 12, 14, 16, 18 Holes | 3, 4, 5, 6, 7, 8, 9 Holes Available |
| Length Range (mm) | 600 mm ~ 1180 mm | 600 mm ~ 1180 mm | 900 mm ~ 2400 mm | 900 mm ~ 2400 mm |
| Width × Height (mm) | 500 × 550 mm | 350 × 550 mm | 750 × 900 mm | 450 × 900 mm |
| Sheet Thickness (mm) | 0.8 mm (Reinforced Rolled Edge) | 0.8 mm (Reinforced Rolled Edge) | 1.2 mm (Heavy Gauge Impact Plate) | 1.2 mm (Heavy Gauge Impact Plate) |
| Material Options | Food-Grade SUS 304 or Economical SUS 201 Stainless Steel | Same as left | Same as left | Same as left |
| Feed Regulating System | Stepless Multi-Gear Feed Drop Gate (Compatible with powder & pelleted feed) | Same as left | Same as left | Same as left |
| Anti-Wastage Design | Curved Interior Trough Bed, Anti-Raking Baffles (Pigs cannot scoop feed out) | Same as left | Same as left | Same as left |
| Weight Range (kg) | 13.4 kg ~ 22.0 kg | 10.0 kg ~ 15.7 kg | 40.8 kg ~ 91.1 kg | 29.5 kg ~ 67.0 kg |
