Dual-hook synchronous overhead inspection system designed to transport cattle heads, hearts, lungs, and livers in tandem with the corresponding carcass for disease screening.
| Parameter | Technical Specification |
|---|---|
| Model Number | NPW-RVC Series |
| Suspension Hook Assembly | Dual-Tier Hooks: Upper hooks for red viscera (heart, liver, lungs); Lower hooks for cattle heads |
| Synchronous Drive Tracking | Closed-loop electronic encoder tracking linked with main cattle slaughter chain |
| Drive Motor Power | 1.5 kW ~ 3.0 kW with Variable Frequency Drive (VFD) |
| Overhead Rail Type | Heavy-Duty Tubular Rail (Φ60 mm) / Closed Track System |
| Automatic Unloading | Automated Mechanical Trip Disengager for Heads and Pluck |
| Sanitizing Cabinet | In-Line Hot Water (82 ℃) High-Pressure Hook Sanitizing Box |
| Frame & Rail Material | Food-Grade SUS 304 Stainless Steel Construction |
| Capacity | Scalable from 20 to 120 head of cattle / h |
