Hygienic material handling and intralogistics conveyor systems including continuous spiral elevators, 90-degree vertical lifts, inclined cleated belts, and curved rollers.
| System Type | Belt Conveyor | Incline Cleated Lift | 90° Vertical Elevator | Continuous Spiral Elevator |
|---|---|---|---|---|
| Model Series | NPW-FCS-BC | NPW-FCS-IC | NPW-FCS-VE | NPW-FCS-SE |
| Conveyor Medium | Food-Grade PU, PVC, or Modular Plastic Belt | Cleated PU Belt / Stainless Steel Wire Mesh | 90° Continuous Platform Bucket Lift | Helical Low-Friction Modular Plastic Chain |
| Incline Angle | Horizontal (0° ~ 15°) | 15° ~ 60° Steep Incline Angles | 90° True Vertical Space-Saving Lift | Continuous Helical Elevation / Decline |
| Frame Material | SUS 304 Stainless Steel Open Frame | SUS 304 Stainless Steel Heavy Chassis | Fully Enclosed SUS 304 Structure | Central SUS 304 Column & Structure |
| Drive & Speed | IP65 Stainless Drum Motor or Geared Motor | Variable Speed Geared Motor | Heavy-Duty Precision Braking Motor | VFD Stepless Speed Synchronized Motor |
| Sanitary Cleanability | Tool-less belt release for quick CIP cleaning | Integrated catch pans and wash ports | Clean-in-place sanitary washdown design | Open spiral bed for thorough sanitization |
| Primary Workflow | Deboning work tables, packaging sorting | Floor-to-chiller transfer, hopper feeding | Multi-tier floor vertical crate transfer | Continuous freezing tunnels, buffer cooling |
