Material Box Automatic Grading Scale

The NPW Material Box Automatic Grading Scale is an innovative and highly efficient solution designed to automate and optimize the weighing and grading processes in various industries. This advanced system replaces traditional manual weighing and grading methods, as well as conventional belt weighing lines, offering superior accuracy, speed, and operational benefits. It is an ideal choice for businesses looking to significantly reduce labor intensity and costs while enhancing overall production efficiency and working conditions.

Key Features & Advantages:

• Automated Precision Sorting: This equipment is engineered to perform continuous, automatic weighing and grading of materials within boxes. It eliminates human error and inconsistencies associated with manual sorting, ensuring precise categorization of products.
• Advanced PLC Control System: At the heart of the system is a sophisticated PLC (Programmable Logic Controller) control system. This intelligent control ensures highly accurate and reliable operation, achieving an impressive sorting accuracy rate of up to 98%.
• Comprehensive System Composition: The machine is robustly constructed from several integrated components, including a main power unit, a stable table unit, a driven unit for movement, a conveying box assembly for material transport, a precise weighing system, and the central PLC control system. This integrated design ensures seamless and efficient operation.
• Significant Labor Cost Reduction: By automating the weighing and grading tasks, the NPW Automatic Grading Scale drastically reduces the need for manual labor. This translates into substantial savings in labor costs and frees up personnel for other critical tasks.
• Improved Operational Environment: The automation of repetitive and physically demanding tasks not only reduces labor intensity but also creates a safer, more comfortable, and more efficient working environment for employees.
• High Sorting Speed: With a sorting speed of up to 180 units per minute, the machine is capable of handling high volumes of products. The optimal speed can be selected and adjusted based on the synchronization requirements of your existing production line, ensuring seamless integration and maximum throughput.
• Multi-Level Grading Capability: The system offers flexible hierarchical grading levels, including 6 (12), 12 (24), and 18 (36) levels, allowing for precise categorization of products based on weight or other criteria up to 5 KG per unit.
• Optimized Dimensions and Power Efficiency: With dimensions of 10800 × 1100 × 1360 mm (height adjustable), the machine is designed for efficient space utilization. The main unit operates with a total power of 2 KW and runs on a standard AC220V 50Hz power supply, ensuring energy efficiency.

Invest in the NPW Material Box Automatic Grading Scale to elevate your production capabilities, achieve unparalleled sorting accuracy, and significantly enhance your operational efficiency and profitability.
