● Material: Hot dipped galvanized, Q235
● Life Time: 20 Years
● Certification: ISO 9001, SONCAP, PVOC
● Tiers: 4-8Tiers
● Chicken House Depth：625 mm
● Feeding Trough: Metal type
● Water Pipe Shape: Square tube
● Water Pipe Thickness: 3mm
● Nipple Drinker： Cone valve
Long-lasting quality, hot-dip galvanized material with 15-20 years service life.
Intensive management and automated control.
No waste of feed, save feed cost.
The sufficient drinking guarantee.
High-density raising saves land and investment.
Automatic control of ventilation and temperature.
| Model |
Tiers |
Doors/set |
Birds/door |
Capacity/set |
Size(L*W*H)mm |
Area/bird(cm²) |
Type |
| RT-LCH3180 | 3 | 5 | 6 | 180 | 2250*600*430 | 450 | H |
| RT-LCH4240 | 4 | 5 | 6 | 240 | 2250*600*430 | 450 | H |
| RT-LCH5300 | 5 | 5 | 6 | 300 | 2250*600*430 | 450 | H |
| RT-LCH6360 | 6 | 5 | 6 | 360 | 2250*600*430 | 450 | H |
In a house of 100m*13m, if 4 tier cages are installed, 39 units of cage per line, the height of side wall should be 4m, and total birds quantity is 37440;if 5 tier cages are installed, 39 units of cage per line, the height of side wall should be 4.5m, and total birds quantity is 46800;if 6 tier cages are installed, 39 units of cage per line, the height of side wall should be 5.0m, and total birds quantity is 56160.
